Infrastructure
CNC TURNING CENTRE - I
| Machine Specification Details |
|---|
| Chuck Dia | 300mm |
| Maximum Turning Length | 700mm |
| Maximum turning Dia | 470mm |
| No of Station | 8 |
CNC TURNING CENTRE - II
| Machine Specification Details |
|---|
| Chuck Dia | 250mm |
| Maximum Turning Length | 500mm |
| Maximum turning Dia | 400mm |
| No of Station | 8 |
VERTICAL MACHINING CENTRE - I
| Machine Specification Details |
|---|
| X Axis Travel | 1020mm |
| Y Axis Travel | 600mm |
| Z Axis Travel | 610mm |
| No of tools | 24 Pockets |
VERTICAL MACHINING CENTRE - II
| Machine Specification Details |
|---|
| X Axis Travel | 850mm |
| Y Axis Travel | 510mm |
| Z Axis Travel | 510mm |
| No of tools | 20 Pockets |
CONVENTIONAL LATHE MACHINE
| Machine Specification Details |
|---|
| Capacity | 15 Tonnes |
KEYWAY & SPLINE BROACHING
| Machine Specification Details |
|---|
| Capacity | 15 Tonnes |
GEAR SHAPING MACHINE
| Machine Specification Details |
|---|
| DIA | 500mm |
| Stroke length | 130mm |
BALANCING MACHINE
| Machine Specification Details |
|---|
| Capacity | 500mm |
| Capacity | 100kgs |
CO-ORDINATE MEASURING MACHINE
| Make | Hexagon Metrology |
| Probe Head | PH10M+ |
| X Travel | 800mm |
| Y Travel | 1000mm |
| Z Travel | 600mm |
2D HEIGHT GAUGE : TRIMOS
| Make | Trimos |
| Measuring Length | 600mm |
